64
MOD553
MOD555
15. Remove the coolant sensor connector from the cool-
ant sensor; then disconnect the coil connectors from
the coils; then remove the engine oil pressure switch
connector from the engine oil pressure switch that is
located near the engine oil filter; then remove the
engine ground located above the engine oil pressure
switch.
MOD556
MOD557
16. Remove the wires going to the alternator; then
remove the temperature/manifold absolute pressure
(TMAP) sensor connector from the temperature/
manifold absolute pressure (TMAP) sensor.
MOD558
MOD559
17. Disconnect the gas line from the injector rail; then
disconnect each injector connector from the injector;
then disconnect the electronic throttle control (ETC)
connector from the ETC.
MOD561
! WARNING
Whenever any maintenance or inspection is made on
the fuel system during which there may be fuel leakage,
there should be no welding, smoking, open flames, etc.,
in the area.
