Tires
Tire Tread Condition
The use of worn-out tires on an ATV is
very dangerous. A tire is considered to
be worn out when the depth of the tread
is less than 3 mm (1/8 in.). Be sure to
replace the tires before reaching this
minimum specification.
Tire Replacement
The ATV has low-pressure tubeless tires. Have this maintenance performed
by an authorized dealer or a qualified tire repair station.
Tubeless Tire Repair
Should a leak or flat tire occur due to a puncture, the tire may be repaired
using a plug-type repair. If the damage is from a cut or if the puncture cannot
be repaired using a plug, the tire must be replaced. When operating the ATV
in areas where transportation or service facilities are not readily available, it is
strongly recommended to carry a plug-type repair kit and a tire pump along.
Wheels
1. Park the ATV on level ground and engage the front brake lever lock
(front) or parking brake (rear).
2. Loosen the wheel nuts on the wheel to be removed.
3. Elevate the ATV.
4. Remove the wheel nuts.
5. Remove the wheel.
6. Install the wheel and install wheel nuts.
7. Tighten in a crisscross pattern to 30 ft-lb.
8. Remove the jack.
Bulb Replacement
The wattage rating of the bulb is shown in the chart. When replacing a
burned bulb, always use the same wattage rating.
! WARNING
Always use the size and type of tires as specified. Refer to the
specifications chart for proper tire inflation pressure, and
always maintain proper tire inflation pressure.
! WARNING
The use of worn-out tires can be dangerous and can increase
the risk of an accident.
! WARNING
Use only approved tires when replacing tires. Failure to do so
could result in unstable ATV operation.
Headlights 12V/15W
Brake Light 12V/P21/5W
CAUTION
Use only specified bulb indicated in the chart as replacement
bulb.
