page 15
TRD-54-T (22.5)
45 MAX.
45 MAX.
45 MAX.
Securing Loads With Chains
NOTE: Only 5/16” or 3/8” Grade 70 Transport Chain is to be used with chain slots
When securing loads with chains, the chains should not exceed angles shown in illus-
trations below.
Viewed from above, chain should not be angled more than 45 degrees in either direc-
tion of chain slot. In addition, chain should not be angled more than 45 degrees above the
trailer floor.
