TrailMax TRD-54-T - Electrical Plug Assembly Components

®
page 51
TRD-54-T (22.5)
Parts
3.6 Electrical
Electrical Plug
Ref. Quantity Description ......................................................................... Part No.
1. 1 Seven Way Plug and Spring .............................................. PL 15-730
Brown-
Tail and Marker
Blue-
ECU Power/Electric Brakes
Black-
Accessories
Yellow-
Left Turn
White-
Ground
Green-
Right Turn
Red-
Stop
1
