TrailMax TRD-54-T - Running Gear and Suspension Parts

®
page 44
TRD-54-T (22.5)
Parts
3.4 Running Gear
For:
Brakes
Bearings and Hubs
Axle End Components
Refer to the Meritor Maintenance Manual 14, Trailer Axles and call Gem State Manu-
facturing at 1-800-447-0213.
Suspension
Ref. Quantity Description ................................................................................... Part No.
1. 2 Axle Assembly, Front and Rear (non ABS)......................... TN4670QH6456
2. 1 Axle Assembly, Center (ABS) ............................................ TN4671QH6455
3. 1 Non-Adjustable Radius Rod .............................................................. 715-00
4. 1 Radius Rod, 19.25” ....................................................................... 16398-04
5. 12 Flanged Locknut ........................................................................... 10562-00
6. 12 Radius Rod Bolt ................................................................................ 719-02
7. 6 3 Leaf High Arch Spring............................................................... TS-365-01
8. 12 U-bolt .............................................................................................. 7816-11
9. 6 Spring Seat ....................................................................................... 301-01
10. 6 Bottom Plate ..................................................................................... 706-01
11. 24 Washer ...............................................................................................35-00
12. 24 Hex Nut ............................................................................................... 34-04
13. 4 Radius Rod, 20.25” ....................................................................... 16398-05
14. 4 Equalizer ....................................................................................... 16160-01
4 Equalizer Bolt Kit ....................................................................... 16353-01
15. 1 Equalizer bolt .......................................................................... 16150-01
16. 1 Locknut ................................................................................... 11154-00
17. 1 Washer ....................................................................................... 837-00
18. 2 Spacer sleeve ............................................................................. 756-00
19. 2 Spacer sleeve bolt ...................................................................... 759-00
20. 2 Hex lock nut .................................................................................. 37-03
21. 6 Spring Brake Chamber, Type 2424 ......................................... B213276X24
Note: Kit names are bold type while component names are regular type; kit components
are indexed under the kit name. Kit component quantities are per kit; other parts and kit quan-
tities are per trailer.
