TrailMax TRD-54-T - Air Brake System Component Catalog

®
page 56
TRD-54-T (22.5)
Parts
3.7 Air Brake System
Because of the complexity of the air brake system, the components are displayed over the
next several pages. For Air Brake Chambers, see section 3.4 - Running Gear.
Ref. Quantity Description .................................................................................. Part No.
1 Tandem Axle Air Kit/ABS .................................................. AK-A2 ABS-PC
1. 1 Service Gladhand .................................................................. PL12-006
2. 1 Emergency Gladhand ............................................................ PL12-008
3. 2 Hose Assembly,
1
/2" x
1
/2" x 60" ......................................TA32003-060
4. 2 Male Elbow,
3
/8" x
3
/8" ............................................. PBVS269NTA-6-6
5. 2 Male Elbow,
1
/2" x
3
/8" .............................................. PBVS269NTA-8-6
6. 3 Terminal Bolt ............................................................................. MI11304
7. 2 90° Union Elbow .............................................................. PB2200P-8-8
8. 360"
1
/2" Nylon Tubing, Red ............................................. NTPF8BREDIN0E
9. 360"
3
/8" Nylon Tubing, Black .................................................. NTPF6BIN0E
10. 1 Air Tank, 1200/2800 cu. in. ......................................................... AT1211
11. 4 Hose Assembly,
3
/8" x
3
/8" x 30" ......................................TA32002-030
12. 4 Hose Assembly,
3
/8" x
3
/8" x 62" ......................................TA32002-062
13. 3 Street Elbow, 90° ............................................................. PB2202P-6-6
14. 1 Drain Cock ......................................................................... PBDC604-4
15. 1 Allen Head Pipe Plug...................................................................... FI3/4
16. 1 Hose Assembly,
3
/8" x
3
/8" x 28" ......................................TA32002-028
17. 1 Electronic Control Unit (ECU) ..................................... OW4005001020
18. 1 Pipe Nipple ............................................................................ F160060E
19. 1 Male Branch Tee
3
/8" x
1
/4" ...................................... PBVS272NTA-6-4
20. 1 Street Elbow, 45° ............................................................. PB2214P-6-6
21. 1 Spring Brake Control Valve ............................................. OS110500OE
22. 2 Allen Head Pipe Plug...................................................................... FI3/8
1 Tri Axle Air Kit ................................................................................... AK A3
23. 30” 3/8” Tubing, Blk ............................................................. NTPFT6BINOE
24. 390” 1/2” Tubing ............................................................ NTPFT8BREDINOE
25. 1 Ears are Opposite 9508/1488 .................................................... AT9534
26. 1 Plug ............................................................................................... F13/4
27. 2 Pipe Plug.................................................................................. F13/8AP
28. 1 Drain Cock ......................................................................... PBDC604-4
29. 4 Street Elbow, 90° ............................................................. PB1202P-6-6
30. 2 Street Elbow, 90° ............................................................. PB2202P-6-6
31. 1 Male Elbow,
3
/8“ x
3
/8“ .............................................. PBVS269NTA-6-6
32. 6 Male Connector,
1
/2“ x
3
/8“ ....................................... PBVS269NTA-8-6
33. 1 Union Tee .......................................................................... PB264NTA-6
34. 1 Union Tee .......................................................................... PB264NTA-8
35. 2 Coupling .................................................................... WW207ACNBH-6
36. 1 M. Connector .............................................................. PBVS68NTA-8-6
37. 1 Spring Brake Control Valve ............................................. OS110500OE
38. 2
3
/8“ x
3
/8“ ........................................................................... TT16152-66
39. 2 Hose Assy-30
3
/8 I.D. Hose-
3
/8 Fxd &
3
/8 SWI ................ TT16130-66
40. 1 Nipple
1
/2 -
3
/4 Male .............................................................. OS616OE
Note: Kit names are bold type while component names are regular type; kit components are indexed
under the kit name. Kit component quantities are per kit; other parts & kit quantities are per trailer.
