TrailMax TRD-54-T - Harnesses and Lights Component List

®
page 52
TRD-54-T (22.5)
Parts
3.6 Electrical
Harnesses and Lights
Because of the complexity of the electrical kit, the components are displayed graphi-
cally over the next several pages.
Ref. Quantity Description......................................................................... Part No.
1 E-17 Electrical Kit .................................................................... E-17
1. 1 Harness, Front Main ..........................................................88776
2. 1 Harness, M/C ‘T’ style 2 plug .............................................88355
3. 1 Harness, Center Main ........................................................88775
4. 1 Harness, M/C ‘T’ style ...............................................88356 0060
5. 1 Harness, Main Feed...........................................................88774
6. 1 Harness, ABS Fault Lamp .........................................52200 0084
7. 1 Harness, M/C ‘T’ style ........................................................88356
8. 1 Harness, S/T/T & ID ...........................................................95582
9. 6 Amber clearance lamp, sealed ....................................... 10205Y
10. 5 Red clearance lamp, sealed ........................................... 10205R
11. 11 Mounting grommet .............................................................10704
12. 4 Oval stop/turn/tail light, sealed ....................................... 60202R
13. 4 Oval mounting grommet .....................................................60700
14. 1 License plate lamp .............................................................26331
15. 1 Amber ABS Fault Lamp, sealed ...................................... 30257Y
16. 1 Mounting grommet .............................................................30700
17. 1 Seven Way Plug and Spring ............................................ PL 15-730
18. 2 *ABS Sensor Extension Cable ............................... OW4497130080
19. 1 *ABS Power Cable ................................................. OW4493260050
Note: Kit names are bold type while component names are regular type; kit com-
ponents are indexed under the kit name. Kit component quantities are per kit; other
parts and kit quantities are per trailer.
*These items are included in the AK-A2 ABS-PC Air Kit and are shown here for refer-
ence only.
