30
18-GJ96D1-1B-EN
Downflow Sensor Relocation:
Note: To avoid damaging the refrigerant sensor, sensor
should be relocated only after field braze joints have
been completed.
1. Remove the coil panel and the line set panel. Locate the
A2L sensor on the upflow drain pan.
2. Remove the A2L sensor from the drain pan by pulling
directly up.
3. Remove the A2L sensor from the metal bracket by
removing the plastic push pins. Keep the push pins as
they will be used later.
FFoouurr--WWaayy CCoonnvveerrssiioonn
