RT-SVX34V-EN
49
Table 19. Power exhaust fan performance—27.5-35 ton—60 Hz
Power Exhaust Selection
50% 100%
Damper Open Position
min max min max
Return Duct Static (in.
wc)
CFM
0.0 3812 6866 7624 13742
0.1 3497 5296 6995 10591
0.2 3190 4458 6325 9000
0.3 2884 3812 5768 7635
0.4 2621 3359 5241 6719
0.5 2342 2885 4683 5771
Note: These values are the minimum and maximum positions for non-tracking power exhaust. Fresh air tracking and Statitrac options can fully close the exhaust dampers
in their operation, and are thus able to reach lower airflows. Statitrac requires 100% power exhaust.
Table 20. Power exhaust fan performance—40-50—60 Hz
Power Exhaust Selection
50% 100%
Damper Open Position
min max min max
Return Duct Static (in.
wc)
CFM
0.0 4854 8035 9708 16069
0.1 4575 7410 9151 14820
0.2 4262 6450 8552 13496
0.3 4011 6027 8021 12054
0.4 3718 5526 7436 11051
0.5 3467 5186 6933 10373
Note: These values are the minimum and maximum positions for non-tracking power exhaust. Fresh air tracking and Statitrac options can fully close the exhaust dampers
in their operation, and are thus able to reach lower airflows. Statitrac requires 100% power exhaust.
Table 21. Power exhaust fan performance—22.9-29.2 tons—50 Hz
Power Exhaust Selection
50% 100%
Damper Open Position
min max min max
Return Duct Static (Pa)
L/s
0.0 1499 2701 2999 5405
24.9 1375 2083 2751 4166
49.8 1255 1753 2488 3540
74.7 1134 1499 2269 3003
Startup
