Trane Technologies Voyager 3 - Unit Wiring Diagram Numbers

90
RT-SVX34V-EN
Unit Wiring Diagram Numbers
Schematic Type Voltage
Diagram
Number
Description
Sheet 1; Power
All
12134517 All Units
Sheet 2; Power
12134518
w/o Supply Fan Bypass
12134519
w/ Supply Fan Bypass
Sheet 3; Symbio 700
12134528 All Units
Sheet 4; Adapter Board
12134529 All Units
Sheet 5; Indoor Options
Module
12134530
w/o Supply Fan Bypass
12134531
w/ Supply Fan Bypass
Sheet 6; Fresh Air
Options Module
12134532 Standard Economizer
12134533 Ultra Low Leak Economizer
Sheet 7; Customer
Connection Module
12134534 All Units
Sheet 8; Stepper Motor
Module
12134535 Reheat
Sheet 9; XM Module
12134448
Expansion Modules
Sheet 10; Heat
Controls
208-230V 12134520 Electric Heat - 208/230V
380-575V
12134521 Electric Heat - 380-575V - 36/54kW
12134522 Electric Heat - 380-575V - 72/90/108kW
All
12134523
Gas Heat - Heater 1 - 2-stage
12134524
Gas Heat - Heater 1 - Modulating
Sheeet 11; Heat
Controls
12134525 Gas Heat - Heater 2
Device Location
12134526
Unit Diagram - Cooling/Electric Heat
12134527
Unit Diagram - Gas Heat
Main Control Panel
VFD Panel
Electric Heat Panel
