Trane Technologies Voyager 3 - Page 52

52
RT-SVX34V-EN
Table 23. 27.5 - 35 Ton downflow economizer (O/A) damper static pressure setup (continued)
System
Design CFM
Return Air Duct Static + Return Air Damper Static (Inches of Water)
0.2 0.4 0.6 0.8 1 1.2 1.4
Drive Rod Position
12000 A A C D E E E
12500 A A C D D E E
13000 A A B B C D E
13500 A A B B C D E
14000 A A A B C D E
14500 A A A B C D D
15000 A A A A B C D
Table 24. 27.5 - 35 Ton horizontal economizer (O/A) damper static pressure setup
System
Design CFM
Return Air Duct Static + Return Air Damper Static (Inches of Water)
0.2 0.4 0.6 0.8 1 1.2 1.4
Drive Rod Position
8000 A F G G G G G
8500 A F G G G G G
9000 A E G G G G G
9500 A E F G G G G
10000 A D E G G G G
11000 A D E F G G G
11500 A B E F G G G
12000 A A D F G G G
12500 A A D E F G G
13000 A A D E F G G
13500 A A C E F F G
14000 A A C D E F G
14500 A A B D E F F
15000 A A B D E F F
15500 A A B D E E F
Table 25. 40 - 50 Ton downflow economizer (O/A) damper static pressure setup
System
Design CFM
Return Air Duct Static + Return Air Damper Static (Inches of Water)
0.2 0.4 0.6 0.8 1 1.2 1.4
Drive Rod Position
12000 A A C D E E E
12500 A A C D D E E
13000 A A B C D E E
13500 A A B C D D E
14000 A A B C C D E
14500 A A B B C D D
Startup
