Trane Technologies Voyager 3 - Page 60

60
RT-SVX34V-EN
Figure 47. 27.5 Ton operating pressure — standard efficiency (60Hz)
150
200
250
300
350
400
450
500
550
600
650
100 110 120 130 140 150 160 170 180 190
Discharge Pressure (Psig)
Suction Pressure (Psig)
COOLING CYCLE PRESSURE CURVE
68/57 F ID WB/DB
74/62 F ID WB/DB
86/72 F ID WB/DB
80/67 F ID WB/DB
65 F OD Ambient
118 F OD Ambient
105 F OD Ambient
95 F OD Ambient
85 F OD Ambient
75 F OD Ambient
55 F OD Ambient
Figure 48. 30 Ton operating pressure — standard efficiency (60 Hz)
150
200
250
300
350
400
450
500
550
600
650
100 110 120 130 140 150 160 170 180 190
Discharge Pressure (Psig)
Suction Pressure (Psig)
COOLING CYCLE PRESSURE CURVE
68/57 F ID
74/62 F ID
86/72 F ID
80/67 F ID
65 F OD Ambient
118 F OD Ambient
105 F OD Ambient
95 F OD Ambient
85 F OD Ambient
75 F OD Ambient
55 F OD Ambient
Startup
