4. Capacities and selection data
The following charts show the characteristics of outdoor unit capacity, which corresponds with
the operating ambient temperature of outdoor unit. Conditions:
① Pipe length / height difference: 25 ft. (7.6m) / 0 ft. (0m)
② Compressor at rated inverter frequency
③ Indoor fan speed at high fan speed
Remarks:
TC: Total Cooling Capacity (Gross) kBtu/h
S/T: Sensible Capacity Ratio
PI: Power Input (including the compressor, cond. fan motor) kW
DB: Dry Bulb Temperature
WB: Wet Bulb Temperature
4.1 Capacity characteristic charts
