10. Installation tools and installation flow chart
10.1 Necessary tools and instrument list for installation
Necessary Tools and Instrument List for Installation
No. Tool No. Tool No. Tool No. Tool
1 Handsaw 6
Copper Pipe
Bender
11 Spanner 16 Leveler
2
Phillips
Screwdriver
7
Manual Water
Pump
12 Charging Cylinder 17
Clamper for
Solderless
Terminals
3 Vacuum Pump 8 Pipe Cutter 13 Gauge Manifold 18
Hoist
(for Indoor Unit)
4
Refrigerant
Gas Hose
9 Brazing Kit 14 Cutter for Wires 19 Ammeter
5 Megohmmeter 10 Hexagon Wrench 15 Gas Leak Detector 20 Voltage Meter
