7. Wiring diagram
27SS-SVM001A-EM
No. Description No. Description
1
Computer/Checker to Outdoor Control
Board
4 S3-Decrease Button
2 7-Segment Display 5 S2-Select Button
3 DIP Switch 6 S1-Increase Button
7-Segment display board
3
