11. Control mode
46 SS-SVM001A-EM
2. THE PARAMETER OF THE OTHER SENSOR: (R
0
=15K±2%;B0/100=3450K±2%)
DR: Deviation Rate
DR(MIN)%= (Rmin-Rnom) / Rnom*100% DR(MAX)%= (Rmax-Rnom) / Rnom*100%
T [ºC] Rmin [ KΩ ] Rnom [ KΩ ] Rmax [ KΩ ] DR(MIN)% DR(MAX)%
-30 60.78 64.77 68.99 -6.16 6.12
-29 57.75 61.36 65.16 -5.88 5.83
-28 54.89 58.15 61.58 -5.61 5.57
-27 52.19 55.14 58.23 -5.35 5.31
-26 49.63 52.30 55.08 -5.11 5.05
-25 47.21 49.62 52.13 -4.86 4.81
-24 44.92 47.10 49.37 -4.63 4.60
-23 42.76 44.73 46.78 -4.40 4.38
-22 40.71 42.49 44.34 -4.19 4.17
-21 38.77 40.38 42.05 -3.99 3.97
-20 36.93 38.39 39.90 -3.80 3.78
-19 35.18 36.51 37.87 -3.64 3.59
-18 33.53 34.74 35.97 -3.48 3.42
-17 31.96 33.06 34.17 -3.33 3.25
-16 30.48 31.47 32.49 -3.15 3.14
-15 29.07 29.97 30.89 -3.00 2.98
-14 27.73 28.56 29.39 -2.91 2.82
-13 26.46 27.22 27.98 -2.79 2.72
-12 25.26 25.95 26.64 -2.66 2.59
- 11 24.11 24.75 25.38 -2.59 2.48
-10 23.03 23.61 24.19 -2.46 2.40
-9 21.99 22.53 23.06 -2.40 2.30
-8 21.01 21.51 22.00 -2.32 2.23
-7 20.08 20.54 20.99 -2.24 2.14
-6 19.19 19.62 20.04 -2.19 2.10
-5 18.35 18.74 19.14 -2.08 2.09
-4 17.55 17.92 18.29 -2.06 2.02
-3 16.78 17.13 17.48 -2.04 2.00
-2 16.06 16.38 16.71 -1.95 1.97
15.36 15.67 15.98 -1.98 1.94
0 14.70 15.00 15.29 -2.00 1.90
1 14.08 14.36 14.64 -1.95 1.91
2 13.48 13.75 14.02 -1.96 1.93
3 12.91 13.17 13.43 -1.97 1.94
4 12.36 12.62 12.87 -2.06 1.94
5 11.85 12.09 12.34 -1.99 2.03
6 11.35 11.59 11.83 -2.07 2.03
7 10.88 11. 11 11.35 -2.07 2.11
8 10.43 10.66 10.89 -2.16 2.11
9 9999 10230 10450 -2.26 2.11
10 9590 9816 10040 -2.30 2.23
11 9199 9422 9647 -2.37 2.33
12 8826 9047 9269 -2.44 2.40
13 8470 8689 8910 -2.52 2.48
14 8129 8347 8567 -2.61 2.57
15 7804 8021 8240 -2.71 2.66
16 7493 7709 7928 -2.80 2.76
17 7196 7412 7630 -2.91 2.86
18 6912 7127 7346 -3.02 2.98
19 6640 6855 7074 -3.14 3.10
20 6381 6595 6815 -3.24 3.23
21 6132 6347 6567 -3.39 3.35
22 5894 6109 6330 -3.52 3.49
