Trane E50 Series User Manual

10
BAS-SVX076C-EN
b. Use three (3) #8 screws (not supplied) to mount the meter to the insdie of the enclosure.
Clip flush with
outside edge
Snap onto
DIN rail
Insert clips from inside
Screw holes
exposed for
mounting
Insert clips from outside
IInnssttaallllaattiioonn

Trane E50 Series Specifications
