Trane E50 Series - Unit Dimensions

BAS-SVX076C-EN
7
Unit Dimensions
4.2 in
(107mm)
3.6 in
(91mm)
1.5 in
(39mm)
2.3 in
(59mm)
1.9 in
(48mm)
1.8 in
(45mm)
3.6 in
(91 mm)
4.2 in
(107 mm)
0.2 in
(4 mm)
3.9 in
(99 mm)
2.4 in
(61 mm)
++
+
4.3 in
(109 mm)
1.2 in
(31 mm)
0.3 in
(8 mm)
0.4 in
(10 mm)
DIN Rail Mount Configuration
(Bottom View)
Overall Dimension
Screw Mount Configuration
(Bottom View)
