BAS-SVX076C-EN
5
Product Identification, Specifications, and Data Outputs
Product Identification
Model: E50H2-T2
Description: BACnet TP Protocol Output
Output: Alarm Output, Full Data Set, Pulse Input
Measurement Accuracy
Real Power and Energy:
IEC 62053-22 Class 0.2S, ANSI C12.20 0.2%
Reactive Power and Energy:
IEC 62053-23 Class 2, 2%
Current:
0.4% (+0.015% per °C deviation from 25°C) from 5% to 100%
of range; 0.8% (+0.015% per °C deviation from 25°C) from 1%
to 5% of range
Voltage:
0.4% (+0.015% per °C deviation from 25°C) from 90 V
L-N
to
600 Vac
L-L
Sample Rate: 2520 samples per second
Data Update Rate:
1 sec
Type of Measurement:
True RMS up to the 21st harmonic 60 Hz; One to three phase AC
system
Input Voltage Characteristics:
Measured AC Voltage:
• Minimum 90 V
L-N
(156 V
L-L
) for stated accuracy
• U.L. Maximum: 600 V
L-L
(347 V
L-N
)
• CE Maximum: 300V
L-N
Metering Over Range:
+20%
Impedance:
2.5M Ω
L-N
/5M Ω
L-L
Frequency Range:
45 Hz to 65 Hz
Input Current Characteristics
CT Scaling: Primary: Adjustable from 5 A to 32,000 A
Measurement Input Range:
0 to 0.333 Vac or 0 to 1.0 Vac (+20% over-range), rated for use
with Class 1 voltage inputs
Impedance: 10.6 kΩ (1/3 V mode) or 32.1 kΩ (1 V mode)
Control Power
AC:
• 5 VA max.; 90 V min.
• UL Maximum: 600 V
L-L
(347 V
L-N
)
• CE Maximum: 300V
L-N
DC:
External DC current limiting is required.
• 3 W maximum
• U.L and CE: 125 Vdc to 300 Vdc
Ride-through Time:
100 milliseconds at 120 Vac
Input
Pulse:
Solid-state or mechanical contacts (current less than 1 mA), 1
pulse input.
Minimum Pulse Width: 20 milliseconds
Output
Alarm Contacts:
N.C., static output (30 Vac/DC, 100 mA maximum @ 25°C,
derate 0.56 mA per °C above 25°C)
