6
BAS-SVX076C-EN
RS-485 Port:
2 wire, 9600 to 115.2 kbaud, BACnet TP
Mechanical Characteristics:
Weight: 0.62 LB. (0.28 kg)
IP40 Degree of Protection (IEC60529): IP40 front display; IP20 Meter
Display Characteristics:
Backlit blue LCD
Terminal Block Screw Torque: 0.37 ft-lb (0.5 N·m) nominal/0.44 ft-lb (0.6 N·m) maximum
Terminal Block Wire Size:
24 AWG to 14 AWG (0.2 to 2.1 mm
2
)
Rail:
T35 (35 mm) DIN Rail per EN50022
Operating Conditions:
Operating Temp: -30°C to 70°C (-22°F to 158°F)
Storage Temp: -40° to 85°C (-40° to 185°F)
Humidity Range: <95% RH (non-condensing)
Altitude of Operation:
3000 m
Agency Compliance
U.S. and Canada:
• CAT III;
• Pollution Degree 2
• For distribution systems up to 347 V
L-N
/600 Vac
L-L
CE:
• CAT III;
• Pollution Degree 2
• For distribution systems up to 300 V
L-N
Dielectric Withstand:
Per U.L. 508, EN61010
Conducted/Radiated Emissions:
FCC part 15 Class B, EN55011/EN61000 Class B (residential and
light industrial)
Conducted/Radiated Immunity: U.L. EN61000 Class A (heavy industrial)
U.S./Canada (cULus) U.L. 508 (open type device)/CSA 22.2 No. 14-05
Europe (CE):
U.L. EN61010-1
Data Outputs (Only BACnet TP)
Full Data Set:
• Power (kW), Energy (kWh)
• Configurable for CT & PT ratios, system type, and passwords
• Diagnostic alerts
• Current/Volts are both 3-phase average
• Volts by phase Line-Line and Line-Neutral
• Power: real, reactive, and apparent 3-phase total and per
phase
• Power factor: 3-phase average and per phase
• Frequency
• Power demand: most recent and peak
• Demand configuration: fixed, rolling block, and external
sync
• Real time clock uses BACnet time synchronization services
PPrroodduucctt IIddeennttiiffiiccaattiioonn,, SSppeecciiffiiccaattiioonnss,, aanndd DDaattaa OOuuttppuuttss
