BAS-SVX076C-EN

Pulse Contact Input

The E50H2-T2 has one input with pulse accumulator as described above, and one phase loss

alarm output terminal.

Figure 3. Pulse Contact Input

SComm

Output

~10 kΩ

Comm

Ground

4-10 VDC

nominal

Equivalent

Circuit

Pulse Input Contacts
