Standard BACnet Default Settings
Setting
Default Values
(a)
BACnet Object
Setup Password 00000 —
Reset Password 00000 —
System Type 40 (3+N) Wye AV2
CT Primary Ratio 100 amp AV3
PT Ratio 1:1 (none) AV5
System Voltage 600 V L-L AV6
Maximum Theoretical Power Calculated from AV2, AV3, AV4,
AV5, and AV6 (with default settings,
power is 103.92 kW
AI45
Display Mode 1 (IEEE) AV7
Phase Loss Voltage Threshold
• 10% of system voltage
• 25% phase-to-phase imbalance
• AV8
• AV9
Demand: Number of sub-intervals
length
1 (block mode) AV10
Demand: Sub-interval Length 900 sec (15 min)- AV11 default
value is 90000 [1/100 seconds]
AV11
BACnet MAC Address 001 —
BACnet TP Baud Rate 76.8 kBaud —
BACnet TP Max_Requestor 127 Device
BACnet Device_ID
Pseudo-random value from
1,000,000 to 3,097,151
Device
BACnet Device Location Installed location not yet identified Device
(a)
Default values are preset at the factory. Once changed, defaults can no longer be automatically reset- they must be restored
individually. The baud rate and MAC address are set through the user-interface screens, and all other values are set by re-
writing each Object.
