18
BAS-SVX076C-EN
User Interface
The user can set the display mode to either IEC or IEEE notation in the SETUP menu.
Table 1. User Interface Menu Abbreviations
Main Menu Main Menu
IEC IEEE Description IEC IEEE Description
D D Demand F ERR F ERR Frequency Error
MAX M Maximum
Demand
I OVR I OVR Over Current
P W Present Real
Power
V OVR V OVR Over Voltage
Q VAR Present
Reactive
Power
PULSE PULSE kWh Pulse Output
Overrun
(configuration
error)
S VA Present
Apparent
Power
_PHASE _PHASE Summary Data for
1, 2, or 3 active
phases
A A Amps ALERT ALERT Diagnostic Alert
Status
UAB, UBC,
UAC
VAB, VBC,
VAC
Voltage Line-
to-Line
INFO INFO
Unit Information
V VLN Voltage Line
to Neutral
MODEL MODEL Model Number
PF PF Power Factor OS OS Operating System
U VLL Voltage Line-
to-Line
RS RS Reset System
HZ HZ Frequency SN SN Serial Number
KSh KVAh Accumulated
Apparent
RESET RESET Reset Data
KQh KVARh Accumulated
Reactive
PASWD PASWD Enter Reset or
Setup Password
KPh KWh Accumulated
Real Energy
ENERG ENERG Reset Energy
Accumulators
PLOSS PLOSS Phase Loss DEMND DEMND Reset Demand
Maximums
LOWPF LOWPF Low Power
Factor Error
