FAXA-SVX01B-EN 39

Installation

electrical

requirements

Table I-ER-9. Electric heat FLA

unit kW kW kW kW kW kW kW kW kW

size voltage 20 26 32 42 56 70 84 100 122

031 208/60/3 55.5 72.2 88.8 116.6 155.4 — — — —

230/60/3 48.1 62.5 77.0 101.0 134.7 — — — —

460/60/3 24.1 31.3 38.5 50.5 67.4 — — — —

040 208/60/3 — 72.2 88.8 116.6 155.4 194.3 233.2 — —

230/60/3 — 62.5 77.0 101.0 134.7 168.4 202.1 — —

460/60/3 — 31.3 38.5 50.5 67.4 84.2 101.0 — —

051 208/60/3 — — 88.8 116.6 155.4 194.3 233.2 277.6 —

230/60/3 — — 77.0 101.0 134.7 168.4 202.1 240.6 —

460/60/3 — — 38.5 50.5 67.4 84.2 101.0 120.3 —

066 208/60/3 — — — 116.6 155.4 194.3 233.2 277.6 338.6

230/60/3 — — — 101.0 134.7 168.4 202.1 240.6 293.5

460/60/3 — — — 50.5 67.4 84.2 101.0 120.3 146.7

Note: Electric heat FLA is determined at 208, 240 & 480 volts.

Table I-ER-10. Dual source electric heat - customer wire gauge, AWG

unit kW kW kW kW kW kW

size voltage 42 56 70 84 100 122

031 208/60/3 1/0 2/0 — — — —

230/60/3 1 1/0 — — — —

040 208/60/3 1/0 2/0 3/0 250 — —

230/60/3 1 1/0 2/0 4/0 — —

051 208/60/3 — — 3/0 250 300 —

230/60/3 — — 2/0 4/0 250 —

066 208/60/3 — — 3/0 250 300 500

230/60/3 — — 2/0 4/0 250 350

Table I-ER-11. Voltage utilization range

utilization

voltage range

208/60/3 187-220

230/60/3 208-254

460/60/3 416-508
