FAXA-SVX01B-EN 7
Installation
general
information
Unit Nameplate
The unit nameplate identifies the unit
model number, appropriate service
literature, and wiring diagram numbers. It
is mounted on the control panel door.
Reference this information when making
inquiries or ordering parts or literature for
the fresh air unit.
Figure I-GI-1. Packaged fresh air unit components
2’’ Pleated filter section with
adjustable rack to 4’’
Standard protective
bird screen on inlet
hood
Traq
®
damper
available for airflow
measurement
Optional return air
damper for unoccupied
recirculation
Non-corrosive IAQ
drain pan sloped in
two directions
Optional condenser
reheat coil with
modulating control
Quiet FC fan
1’’ Solid double-wall
panels of foamed-
in-place construc-
tion
Hi-rise electric
(or gas) heat
Horizontal or vertical
discharge openings
Unit mounted IntelliPak
®
microprocessor control
with easy-to-read human
interface
All ship-with items are
inside this compartment
