FAXA-SVX01B-EN 5
Installation
general
information
F = zone dehumidification with OA RH
reference
G= supply air temperature control (no
dehumidification)
J = zone temperature control (no
dehumidification)
Digit 31 – Control interface options
0 = none
A = LonTalk
®
communications interface
(LCI ) (comm5)
B = LCI (comm5) & generic building
automation system (GBAS) (0-5 VDC)
C = LCI (comm5) & GBAS (0-5 VDC) &
ventilation override module (VOM)
D = LCI (comm5) & VOM
E = GBAS (0-5 VDC)
F = GBAS (0-5 VDC) & VOM
G= VOM
Digit 32 – Miscellaneous system control
options
0 = none
1 = interface for remote human interface
Digit 33 – Exhaust option
0 = none
1 = exhaust interface
Digits 34, 35, 36 – Exhaust air fan rpm
000 = none
045 = 450
047 = 475
050 = 500
052 = 525
055 = 550
057 = 575
060 = 600
062 = 625
065 = 650
067 = 675
070 = 700
072 = 725
075 = 750
077 = 775
080 = 800
082 = 825
085 = 850
087 = 875
090 = 900
092 = 925
095 = 950
097 = 975
100 = 1000
102 = 1025
105 = 1050
107 = 1075
110 = 1100
112 = 1125
115 = 1150
117 = 1175
120 = 1200
122 = 1225
125 = 1250
Digits 37, 38 – Exhaust air fan horsepower
00 = none
01 = 1
02 = 2
03 = 3
05 = 5
07 = 7.5
10 = 10
Digit 39 – Unit connection type
A = terminal block
B = non-fused disconnect switch
Digit 40 – Convenience outlet
0 = none
A = 115V, factory wired
B = 115V, field wired
Digit 41 – Extended grease lines
0 = none
A= extended grease lines
Digit 42 – Agency approval
0 = no agency approval
A = UL approval
Digit 43 – Roof curb
A = 14” curb
B = 24” curb
127 = 1275
130 = 1300
132 = 1325
135 = 1350
137 = 1375
140 = 1400
142 = 1425
145 = 1450
147 = 1475
150 = 1500
152 = 1525
155 = 1550
157 = 1575
160 = 1600
162 = 1625
165 = 1650
167 = 1675
170 = 1700
172 = 1725
175 = 1750
177 = 1775
180 = 1800
182 = 1825
185 = 1850
187 = 1875
190 = 1900
192 = 1925
195 = 1950
197 = 1975
200 = 2000
202 = 2025
205 = 2050
207 = 2075
210 = 2100
