Trane GAM5 Series User Manual

37
Section 18. Start Up
18.1 System Charge Adjustments
The following combinations should be charged to 8
degrees sub-cooling to maintain rated HSPF.
Indoor Unit Model No. Outdoor Unit Model No.
GAM5A0A18M11SAA 4A6B4018E1
4A6H5018E1
GAM5A0A24M21SAA 4A6B4024E1
4A6H5024E1
GAM5A0B30M21SAA 4A6B4030E1
4A6H5030E1
GAM5A0B36M31SAA 4A6B4036E1
4A6H5036E1
GAM5A0C42M31SAA
GAM5A0C48M41SAA 4A6B4048E1
4A6H5048E1
4A6B4049E1
4A6H5049E1
GAM5A0C60M51SAA 4A6B4060E1
4A6H5060E1
4A6B4061E1
4A6H5061E1
All other non-rated matches must be charged
per the nameplate charging instructions.
The following combinations should be charged to 8
degrees sub-cooling to maintain rated HSPF.
Indoor Unit Model No. Outdoor Unit Model No.
GAM5A0A18M11SAA 4TWB4018E1
4TWR5018E1
GAM5A0A24M21SAA 4TWB4024E1
4TWR5024E1
GAM5A0B30M21SAA 4TWB4030E1
4TWR5030E1
GAM5A0B36M31SAA 4TWB4036E1
4TWR5036E1
GAM5A0C42M31SAA
GAM5A0C48M41SAA 4TWB4048E1
4TWR5048E1
4TWB4049E1
4TWR5049E1
4TWX5049E1
GAM5A0C60M51SAA 4TWB4060E1
4TWR5060E1
4TWB4061E1
4TWR5061E1
4TWX5061E1
All other non-rated matches must be charged
per the nameplate charging instructions.

Trane GAM5 Series Specifications

General

Type	Air Handler
Series	GAM5
Refrigerant Compatibility	R-410A
Voltage	208/230V
Phase	Single
Nominal Cooling Capacity	1.5 to 5 tons
Cabinet Construction	Galvanized steel
Heating Capacity	Varies by model
Airflow Configuration	Upflow, Downflow, Horizontal
Sound Level	Varies by model
Motor Type	Variable Speed
