43
WHEEL
BLOWER HOUSING
BELLY BAND
MOTOR
A
A is determined per chart
Wheel is centered in
Blower Housing
MODEL DIM "A"
GAM5B0A18M11EB 1-1/8
GAM5B0A24M21EB 1-1/8
GAM5B0B36M31EB 1-1/2
GAM5B0C42M31EB 1-1/2
GAM5B0C48M41EB 2-1/4
GAM5B0C60M51EB 2-1/4
Section 18. Distance From Belly Band To Shaft Face Of Motor For
Minimum Vibration
