Page #33 background imageLoading...
Page #33 background image
33
MODEL
RATED VOLTS/PH/HZ.
RATINGS ①
INDOOR COIL — Type
Rows — F.P.I.
Face Area (sq. ft.)
Tube Size (in.)
Refrigerant Control
Drain Conn. Size (in.) ②
DUCT CONNECTIONS
INDOOR FAN — Type
Diameter-Width (In.)
No. Used
Drive - No. Speeds
CFM vs. in. w.g.
No. Motors — H.P.
Motor Speed RPM
Volts/Ph/Hz
F.L. Amps
FILTER
Filter Furnished?
Type Recommended
No.-Size-Thickness
REFRIGERANT
Ref. Line Connections
Coupling or Conn. Size — in. Gas
Coupling or Conn. Size — in. Liq.
DIMENSIONS
Crated (In.)
Uncrated
WEIGHT
Shipping (Lbs.) / Net (Lbs.)
MODEL
RATED VOLTS/PH/HZ.
RATINGS ①
INDOOR COIL — Type
Rows — F.P.I.
Face Area (sq. ft.)
Tube Size (in.)
Refrigerant Control
Drain Conn. Size (in.) ②
DUCT CONNECTIONS
INDOOR FAN — Type
Diameter-Width (In.)
No. Used
Drive - No. Speeds
CFM vs. in. w.g.
No. Motors — H.P.
Motor Speed RPM
Volts/Ph/Hz
F.L. Amps
FILTER
Filter Furnished?
Type Recommended
No.-Size-Thickness
REFRIGERANT
Ref. Line Connections
Coupling or Conn. Size — in. Gas
Coupling or Conn. Size — in. Liq.
DIMENSIONS
Crated (In.)
Uncrated
WEIGHT
Shipping (Lbs.) / Net (Lbs.)
GAM5B0C60M51EB
208-230/1/60
See O.D. Specifications
Plate Fin
4 - 14
5.96
3/8
TXV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 10
1
Direct - 5
See Fan Performance Table
1 - 1
1050
208-230/1/60
7.6
No
Throwaway
1 - 22 X 20 - 1 in.
R-410A
Brazed
7/8
3/8
H x W x D
63-1/4 x 27-1/2 x 25-3/4
61-3/4 x 23-1/2 x 21-3/4
180/170
GAM5B0A18M11EB
208-230/1/60
See O.D. Specifications
Plate Fin
3 - 14
3.67
3/8
TXV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 8
1
Direct - 5
See Fan Performance Table
1 - 1/3
1050
208-230/1/60
2.8
No
Throwaway
1 - 16 X 20 - 1 in.
R-410A
Brazed
3/4
3/8
H x W x D
51-3/8 x 20-1/2 x 25-3/4
49-7/8 x 17-1/2 x 21-3/4
126/120
GAM5B0A24M21EB
208-230/1/60
See O.D. Specifications
Plate Fin
3 - 14
3.67
3/8
TXV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 8
1
Direct - 5
See Fan Performance Table
1 - 1/3
1050
208-230/1/60
2.8
No
Throwaway
1 - 16 X 20 - 1 in.
R-410A
Brazed
3/4
3/8
H x W x D
51-3/8 x 20-1/2 x 25-3/4
49-7/8 x 17-1/2 x 21-3/4
126/120
GAM5B0B36M31EB
208-230/1/60
See O.D. Specifications
Plate Fin
3 - 14
5.04
3/8
TXV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 10
1
Direct - 5
See Fan Performance Table
1 - 1/2
1050
208-230/1/60
4.1
No
Throwaway
1 - 20 X 20 - 1 in.
R-410A
Brazed
7/8
3/8
H x W x D
57-1/4 x 24-1/4 x 25-3/4
55-3/4 x 21-1/4 x 21-3/4
150/142
GAM5B0C42M31EB
208-230/1/60
See O.D. Specifications
Plate Fin
4 - 14
5.04
3/8
TXV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 10
1
Direct - 5
See Fan Performance Table
1 - 1/2
1050
208-230/1/60
4.1
No
Throwaway
1 - 22 X 20 - 1 in.
R-410A
Brazed
7/8
3/8
H x W x D
58-1/2 x 27-1/2 x 25-3/4
56-7/8 x 23-1/2 x 21-3/4
163/153
GAM5B0C48M41EB
208-230/1/60
See O.D. Specifications
Plate Fin
4 - 14
5.96
3/8
TXV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 10
1
Direct - 5
See Fan Performance Table
1 - 3/4
1050
208-230/1/60
6.0
No
Throwaway
1 - 22 X 20 - 1 in.
R-410A
Brazed
7/8
3/8
H x W x D
63-1/4 x 27-1/2 x 25-3/4
61-3/4 x 23-1/2 x 21-3/4
176/166
These Air Handlers are A.R.I. certified with various Split System Air Conditioners and Heat Pumps (ARI
STANDARD 210/240). Refer to the Split System Outdoor Unit Product Data Guides for performance data.
3/4" Male Plastic Pipe (Ref.: ASTM 1785-76)
