23.1 Adjustments for 2-Stage outdoor AC models
16 SEER Cooling Models
OD MODEL ID MODEL SPEED TAP SYSTEM STAGE CFM ESP
4TTR6024A*
4TTX6024G*
4A7A6024G*
GAM5B0A24M21*
4 H 800 0.333
2 L 725 0.273
4TTR6036A*
4TTX6036G*
4A7A6036G*
GAM5B0B36M31*
4 H 1225 0.357
3 L 1070 0.272
4TTR6036A*
4TTX6036G*
4A7A6036G*
GAM5B0C42M31*
3 H 1225 0.400
2 L 1115 0.331
4TTR6048A*
4TTX6048G*
4A7A6048G*
GAM5B0C48M41*
3 H 1500 0.381
2 L 1415 0.339
4TTR6060A*
4TTX6060E*
4A7A6060E*
GAM5B0C60M51*
3 H 1700 0.390
2 L 1645 0.365
17 SEER Cooling Models
OD MODEL ID MODEL SPEED TAP SYSTEM STAGE CFM ESP
4TTR7024A*
4TTX7024A*
4A7A7024A*
GAM5B0A24M21*
4 H 800 0.333
2 L 725 0.273
4TTR7036A*
4TTX7036A*
4A7A7036A*
GAM5B0B36M31*
4 H 1225 0.357
3 L 1070 0.272
4TTR7036A*
4TTX7036A*
4A7A7036A*
GAM5B0C42M31*
3 H 1225 0.400
2 L 1115 0.331
4TTR7048A*
4TTX7048A*
4A7A7048A*
GAM5B0C48M41*
3 H 1475 0.449
2 L 1390 0.399
4TTR7060A*
4TTX7060A*
4A7A7060A*
GAM5B0C60M51*
3 H 1700 0.390
2 L 1645 0.365
NOTES
1) Speed Tap settings must be changed for two stage operation
2) Speed Tap settings listed are for the rated ESP, settings may be different depending on your ESP
3) Minimum airflow for electric heat must be maintained. (High Stage)
Section 23. 2-Stage Outdoor Adjustment
