8
STEP 4 - Slide Blower assembly out of unit using
built-in blower support channels and set aside.
Note: Remove the cardboard from the bottom of
the blower. Cut the tie wrap and remove the foam
block located at the motor.
Blower Support
Channel
STEP 5 - Slide Coil assembly out of unit using built-
in coil support channels and set aside.
Coil Support
Channel
To Next Page
