Trane GECK006 - Page 19

WSHP-SVX022A-EN
19
Figure 14. GEC 0.5 to 1.5 tons (60 Hz) - chassis + standard factory configuration (RH)
42 1/4''
11 1/2''
2 1/8''
1 1/2''
2 3/8''
21 7/8''
3''
1 7/8''
3 3/4''
18 1/2''
3 3/4''
6''
33''
1 3/4''
5 1/4''
2 1/2''
16 3/8''
4''
6 1/4''
10 1/2''
5/8''
2''
24 1/4''
6 1/4''
15''
1 3/4''
3/4''
9 1/4''
48''
RIGHT SIDE
VIEW
FRONT VIEW
BACK VIEW
WATER OUT
.625 ODS.
AIR SIDE
SERVICE PANEL
REFRIGERATION
SERVICE PANEL
WATER IN
.625 ODS.
6.0'' LONG .625 I.D.
PLASTIC HOSE PROVIDE FOR
CONDENSATE CONNECTION
CONTROL BOX
SERVICE PANEL
TOP VIEW
RECEPTACLE BOX
CUT OUT FOR
LOW VOLTAGE
TERM INAL STRIP
Unit Dimensions
