Trane GECK006 - Water Volume

36
WSHP-SVX022A-EN
Table 8. Cooling water pressure drops (WPD) in feet of head for GEC* units - 0.5 to 1.5 tons
Unit Size (60 Hz)
EWT °F GPM Ft. Pressure
006 86 1.8 3.4
009 86 2.1 4.4
012 86 2.8 9.4
015 86 3.5 14.0
018 86 4.2 11.7
Table 9. Heating water pressure drops (WPD) in feet of head for GEC* units - 0.5 to 1.5 tons
Unit Size (60 Hz)
EWT °F GPM Ft. Pressure
006 68 1.8 3.6
009 68 2.1 4.7
012 68 2.8 10.0
015 68 3.5 14.8
018 68 4.2 12.4
Water Volume
See Table 10, p. 36 to calculate glycol requirements for the
unit.
Table 10. Water volume for GEC* units
Unit Size
(60 Hz)
Water Side
Volume (in
3
)
Water Side
Volume (ft
3
)
Water Side
Volume
(gallons)
006-009 13.6 0.008 0.059
012-015 23.1 0.013 0.100
018 36 0.021 0.156
Start-Up
