Trane GECK006 - Page 34

34
WSHP-SVX022A-EN
Table 7. Operating pressures in cooling/heating for GEC* units 60Hz
Model
Entering
Water
Temp (°F)
Water Flow
(GPM)
Cooling Heating
Suction
Pressure,
(psig)
Discharge
Pressure,
(psig)
Water
Temp Rise
(°F)
Air Temp
Drop (°F DB)
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Drop (°F)
Air Temp
Rise
(°F DB)
GEC*006 35° 1.4 — — — — 71-87 228-279 6-8 16-20
GEC*006 35° 1.8 — — — — 73-89 230-281 5-6 17-20
GEC*006 45° 1.4 112-137 168-205 14-17 23-28 82-100 238-291 7-9 20-25
GEC*006 45° 1.8 112-137 158-193 11-13 23-28 84-103 240-293 6-7 21-25
GEC*006 55° 1.4 114-139 197-241 14-17 23-28 97-118 250-306 9-11 23-28
GEC*006 55° 1.8 113-139 189-232 11-13 23-28 100-122 253-309 7-9 24-29
GEC*006 68° 1.4 118-144 231-282 13-16 22-27 112-137 263-322 10-13 27-33
GEC*006 68° 1.8 117-143 224-273 10-13 22-27 116-141 266-326 8-10 28-34
GEC*006 75° 1.4 125-152 259-317 14-17 22-27 124-152 273-334 11-14 29-36
GEC*006 75° 1.8 124-152 250-306 11-13 22-27 129-158 277-338 9-11 30-37
GEC*006 86° 1.4 127-156 298-364 13-16 21-26 146-179 289-354 13-16 32-40
GEC*006 86° 1.8 127-155 289-353 10-13 21-26 153-186 293-359 10-13 33-41
GEC*006 95° 1.4 130-158 331-404 13-15 21-25 — — — —
GEC*006 95° 1.8 129-158 321-392 10-12 21-25 — — — —
GEC*009 35° 1.7 — — — — 72-89 227-278 5-7 16-19
GEC*009 35° 2.1 — — — — 74-91 229-279 4-5 16-20
GEC*009 45° 1.7 113-138 160-195 12-14 23-28 83-102 237-290 6-8 20-24
GEC*009 45° 2.1 113-138 153-187 9-12 23-28 85-104 239-292 5-6 20-25
GEC*009 55° 1.7 114-140 191-234 12-14 22-27 100-122 250-305 7-9 23-28
GEC*009 55° 2.1 114-139 186-227 9-12 22-27 102-125 251-307 6-8 23-28
GEC*009 68° 1.7 118-144 225-275 11-14 21-26 115-140 262-320 9-11 26-32
GEC*009 68° 2.1 117-143 220-269 9-11 22-26 118-144 264-323 7-9 27-33
GEC*009 75° 1.7 125-153 252-308 11-14 22-27 128-156 272-332 10-12 29-35
GEC*009 75° 2.1 125-153 246-301 9-11 22-27 131-160 275-336 8-10 29-36
GEC*009 86° 1.7 128-156 291-355 11-13 21-26 151-184 288-352 11-14 32-39
GEC*009 86° 2.1 127-156 284-348 9-11 21-26 155-190 291-356 9-11 32-40
GEC*009 95° 1.7 130-159 323-395 10-13 20-25 — — — —
GEC*009 95° 2.1 130-159 316-386 9-10 20-25 — — — —
GEC*012 35° 2.2 — — — — 72-88 242-295 6-7 16-20
GEC*012 35° 2.8 — — — — 74-90 243-297 5-6 17-20
GEC*012 45° 2.2 115-140 173-211 13-16 23-28 86-105 256-313 7-8 19-24
GEC*012 45° 2.8 114-139 156-190 10-13 23-28 88-108 258-315 5-7 20-24
GEC*012 55° 2.2 117-143 192-234 13-16 22-27 102-125 269-329 8-10 22-27
GEC*012 55° 2.8 116-142 186-227 10-12 22-27 105-129 272-332 6-8 23-28
GEC*012 68° 2.2 120-147 225-275 12-15 22-26 121-148 286-350 9-11 25-31
GEC*012 68° 2.8 120-146 219-268 10-12 22-26 125-153 290-354 7-9 26-32
GEC*012 75° 2.2 122-149 247-302 12-15 21-26 134-164 297-363 10-12 27-33
GEC*012 75° 2.8 121-148 241-294 10-12 22-26 139-170 300-367 8-10 28-34
Start-Up
