Table 1. GR Roof Curb Kit Dimensions (continued)
Rooftop
Arrange-
ment
Capaci-
ty
Trane P/N
F G H J
Q
R K M W B C
D
20/25
0134-0205-
13
29-5/8 8-1/8 71-1/8 67-3/8
69
76-3/8 1-1/2 1-1/2 37-7/16 41-3/16 46-7/16
(752) (206) (1,806) (1,711) (1,753) (1,940) (38) (38) (951) (1,046) (1,179)
D
30/35
0134-0205-
14
29-5/8 8-1/8 71-1/8 67-3/8
69
76-3/8 1-1/2 1-1/2 48-7/16 52-3/16 57-7/16
(752) (206) (1,806) (1,711) (1,753) (1,940) (38) (38) (1,230) (1,325) (1,459)
D 40
0134-0205-
15
29-5/8 8-1/8 71-1/8 67-3/8
69
76-3/8 1-1/2 1-1/2 53-15/16 57-11/16 62-15/16
(752) (206) (1,806) (1,711) (1,753) (1,940) (38) (38) (1,370) (1,465) (1,599)
D 50
0134-0205-
16
29-5/8 34-1/8 97-1/8 93-3/8
95
102-3/8 1-1/2 1-1/2 37-7/16 41-3/16 46-7/16
E
20/25
(752) (867) (2,467) (2,371) (2,413) (2,600) (38) (38) (951) (1,046) (1,179)
D
60/70
0134-0205-
17
29-5/8 34-1/8 97-1/8 93-3/8
95
102-3/8 1-1/2 1-1/2 48-7/16 52-3/16 57-7/16
E
30/35
(752) (867) (2,467) (2,371) (2,413) (2,600) (38) (38) (1,230) (1,325) (1,459)
D 80
0134-0205-
18
29-5/8 34-1/8 97-1/8 93-3/8
95
102-3/8 1-1/2 1-1/2 53-15/16 57-11/16 62-15/16
E 40
(752) (867) (2,467) (2,371) (2,413) (2,600) (38) (38) (1,370) (1,465) (1,599)
E
10/15
0134-0205-
19
29-5/8 34-1/8 97-1/8 93-3/8
95
102-3/8 1-1/2 1-1/2 26-7/16 30-3/16 35-7/16
(752) (867) (2,467) (2,371) (2,413) (2,600) (38) (38) (671) (767) (900)
E 50
0134-0205-
20
30-1/8
59 123
119-1/4 120-7/8 128-1/4 1-1/2 1-1/2 37-7/16 41-3/16 46-7/16
(765) (1,499) (3,124) (3,029) (3,070) (3,257) (38) (38) (951) (1,046) (1,179)
E
60/70
0134-0205-
21
30-1/8
59 123
119-1/4 120-7/8 128-1/4 1-1/2 1-1/2 48-7/16 52-3/16 57-7/16
(765) (1,499) (3,124) (3,029) (3,070) (3,257) (38) (38) (1,230) (1,325) (1,459)
E 80
0134-0205-
22
30-1/8
59 123
119-1/4 120-7/8 128-1/4 1-1/2 1-1/2 53-15/16 57-11/16 62-15/16
(765) (1,499) (3,124) (3,029) (3,070) (3,257) (38) (38) (1,370) (1,465) (1,599)
G
20/25
0134-0205-
23
37-3/16 29-3/16 107-5/16 103-9/16 105-3/16 112-9/16 1-1/2 1-1/2 37-7/16 41-3/16 46-7/16
(944) (741) (2,726) (2,631) (2,672) (2,859) (38) (38) (951) (1,046) (1,179)
G
30/35
0134-0205-
24
37-3/16 29-3/16 107-5/16 103-9/16 105-3/16 112-9/16 1-1/2 1-1/2 48-7/16 52-3/16 57-7/16
(944) (741) (2,726) (2,631) (2,672) (2,859) (38) (38) (1,230) (1,325) (1,459)
G 40
0134-0205-
25
37-3/16 29-3/16 107-5/16 103-9/16 105-3/16 112-9/16 1-1/2 1-1/2 53-15/16 57-11/16 62-15/16
(944) (741) (2,726) (2,631) (2,672) (2,859) (38) (38) (1,370) (1,465) (1,599)
