System Operating Status
The following screens are displayed for 20 through 60 Ton units.
Used on Units:
20 thru 60 Ton Units
Possible Values:
K3 - On, Off, Locked,
K4 - On, Off, Locked,
1. Press the NEXT key until the following screen is displayed. K11 - On, Off, Locked, or
K12 - On, Off, Locked
1. Press the NEXT key until the following screen is displayed.
The following screens are displayed for 40 through 60 Ton units.
1. Press the NEXT key until the following screen is displayed.
Disabled By:
Bad Cond Temp Sensor Hot Start Operation
Bad Ent Soln Sensor Low Ambient Lockout
Bad Leav Soln Sensor Low Leav Soln Cutout
Compressor Protection Low Pressure Cutout
Compressor Protect LPC LPC Delay
Contactor Failure Minimum Off Time
Demand/Capacity Limit Over/Under Voltage
Evap Flow Protection Phase Loss/Reversal
Evap Limit Control Tracer Lockout
1. Press the NEXT key until the following screen is displayed.
Used on Units:
All Units
Possible Values:
-40 to 200 F
1. Press the NEXT key until the following screen is displayed.
The following three screens are applicable when Superheat
/
Subcool Module is installed.
Used on Units:
With superheat/subcool module
Possible Values:
-40 to 200 F
1. Press the NEXT key until the following screen is displayed.
Used on Units:
With superheat/subcool module
Possible Values:
Suction range 0 - 100 PSIG
Liquid range 0 - 400 PSIG
1. Press the NEXT key until the following screen is displayed. Comp Off
Used on Units:
With superheat/subcool module
Possible Values:
0 - 99.9 F
Comp Off
1. Press the NEXT key until the following screen is displayed.
The following screens are displayed for 40 through 60 Ton units.
Used on Units:
40 Thru 60 Ton Units
Possible Values:
-40 to 200 F
Compressor Relay K11 Off
Enabled
Compressor Relay K12 Off
Enabled
Compressor Relay K3 Off
Enabled
Compressor Relay K4 Off
Enabled
Compressor Module Ckt 1
Saturated Condensor Temperature 81.0 F
Refrigerant Ckt 1 - Temperature Data
Suction 75.0 F Sat Liquid 81.0 F
Refrigerant Ckt 1 - Pressure Data
Suction 72 PSIG Li
q
uid 265 PSIG
Refrigerant Circuit 1
Su
p
erheat 28.0 F Subcoolin
g
18.0 F
Compressor Module Ckt 2
Saturated Condenser Temperature 97.0 F
