System Testing & Troubleshooting
and then the following screen will be displayed
and then the following screen will be displayed
OR
3. Pressing the "NEXT" key to view the diagnostics will prompt the
following screen if a "MANUAL RESET" failure has occurred.
Used on Units:
All Units
The word MORE will only appear if more than one failure has
occurred.
Possible Values:
Comp Contactor Fail - Ckt 1 Evap Leaving Solution Temp Sensor Fail
Comp Contactor Fail - Ckt 2 Evap Entering Solution Temp Sensor Fail
Comp Prot - LPC Open (Ckt 1) Evap Solution Flow Loss
Comp Prot - LPC Open (Ckt 2) Hot Start Load Limit (Man)
Compressor Trip - Ckt 1 Low Solution Cutout Temp (Man)
Compressor Trip - Ckt 2 Low Pressure Control Open - Ckt 1
Emergency Stop Low Pressure Control Open - Ckt 2
Resetting Active Manual Diagnostics
U
datin
Unit Data
Please Wait
Resetting Active Manual Diagnostics
Sendin
Reset Re
uest
Active Diagnostic ---- Info
"Please Wait . . . Unit Is In Reset Mode"
Active Diagnostic ---- Manual Reset
More
OR
Pressing the "NEXT" key to view the diagnostics will prompt the
Used on Units:
All Units
following screen if an "AUTO RESET" failure has occurred.
The word MORE will only appear if more than one failure has occurred.
Possible Values:
CGM OA Temp Sensor Failure, IBTS Adjusted to Maintain Min Diff
CGM Zone Temp Sensor Failure, Ice Build Terminate Setpoint Fail
Cond Temp Sensor Failure - Ckt 1, Leaving Solution Setpoint Fail
Cond Temp Sensor Failure - Ckt 2, Low Ambient Evap Solution Pump Override
Current Sensing Module Comm Fail Low Solution Cutout Temp (Auto)
Evap Solution Flow Proving Switch LSS Adjusted to Maintain Min Diff
Ext. Leaving Solution STP Input Fail MCM Communications Failure
GBAS 0-5V Module Comm Failure SCM Communications Failure
GBAS 0-10V Module Comm Fail BAS Module Comm Failure
Hot Start Load Limit (Auto) BAS/NETWORK Comm Failure
Hot Start Load Limit STP Fail Unit HI Communications Failure
OR
Pressing the "NEXT" key to view the diagnostics will prompt the following
screen if an "Information Only" failure has occured.
Active Diagnostic ---- Auto Reset
More
To Next Page
