Trane IntelliPak Signature Series User Manual

58 SCXF-SVX01B-EN
Installation
Start-Up Log
Complete this log at unit start-up.
Unit: ____________________________ Unit Location: _________________________________________
Unit Voltage: __________ __________ __________
A B C
Evaporator:
Evaporator fan motor horsepower: __________ Evaporator fan motor amps: __________ __________ __________
A B C
Evaporator fan RPM (actual): ____________________
Evaporator System Static (from test and balance report or actual readings):
Supply Duct Static: __________
Return Duct Static: __________
Evaporator Air Conditions with both compressors operating:
Enter: Leaving:
Dry Bulb - F: __________ Dry Bulb - F: __________
Wet Bulb - F: __________ Wet Bulb - F: __________
Evaporator System CFM (test and balance sheet or actual tested): __________
___________________________________________________________________________________________________________________________
Compressor Amp Draw:
Circuit A: __________ __________ __________ Circuit B: __________ __________ __________
A B C A B C
Circuit C: __________ __________ __________ Circuit D: __________ __________ __________
A B C A B C
Suction Pressure - psig: Circuit A: __________ Circuit B: __________ Circuit C: __________ Circuit D: __________
Discharge Pressure - psig: Circuit A: __________ Circuit B: __________ Circuit C: __________ Circuit D: __________
Super Heat - F: Circuit A: __________ Circuit B: __________ Circuit C: __________ Circuit D: __________
Liquid Line Pressure - psig: Circuit A: __________ Circuit B: __________ Circuit C: __________ Circuit D: __________
Sub Cooling - F: Circuit A: __________ Circuit B: __________ Circuit C: __________ Circuit D: __________
___________________________________________________________________________________________________________________________
Start-Up
