SCXF-SVX01B-EN 59
Installation
Start-Up
Water Cooled Units:
Circuit A:
Entering Water Temperature - F: __________ Leaving Water Temperature - F: __________
Entering Water Pressure - psig: __________ Leaving Water Pressure - psig: __________
Circuit B:
Enter Water Temperature - F: __________ Leaving Water Temperature - F: __________
Entering Water Pressure - psig: __________ Leaving Water Pressure - psig: __________
Circuit C:
Entering Water Temperature - F: __________ Leaving Water Temperature - F: __________
Entering Water Pressure - psig: __________ Leaving Water Pressure - psig: __________
Circuit D:
Enter Water Temperature - F: __________ Leaving Water Temperature - F: __________
Entering Water Pressure - psig: __________ Leaving Water Pressure - psig: __________
___________________________________________________________________________________________________________________________
Air Cooled Units:
(Data taken from outside condensing unit)
Voltage: __________ __________ __________ Amp Draw: __________ __________ __________
A B C A B C
Entering Air Temperature - F: __________ Leaving Air Temperature - F: __________
Refrigerant Pressures at condenser - psig: __________/ __________ Sub cooling at condenser - F: __________
