Trane JDAC Series User Manual

51
I
GB
F
51
I
GB
F
TECHNICAL
DATA
AIR-COOLED
DATI TECNICI
CONDENSAZIONE
AD ARIA
DONNEES
TECHNIQUES
CONDENSATION
PAR AIR
MODELLO MODEL MODÈLE 0115B 0115A 0125B 0125A 0133A 0135A 0150A 0160A
UMIDIFICATORE AD
ELETTRODI
ELECTRODE HUMIDIFIER
HUMIDIFICATEUR A
VAPEAUR
Produzione nominale di vapore Nominal steam output Production de vapeur nominale
Kg/h 2,0 2,0 2,0 2,0 2,0 2,0 3,0 3,0
Potenza nominale Nominal power Puissance nominale
kW 1,44 1,44 1,44 1,44 1,44 1,44 2,16 2,16
PRESA ARIA DI RINNOVO FRESH AIR FILTER MODULE AIR NEUF
Diametro di connessione Connection diameter Raccordement
mm 80 80 80 80 80 80 80 80
Portata aria nominale Nominal air flow rate Débit d’air nominale
m
3
/h 90 90 90 90 90 90 90 90
POMPA SCARICO
CONDENSA
(versione C)
CONDENSATE
DRY PUMP
(C version)
POMPE DE DESCHARGE
DE LA CONDENSAZATION
(version C)
Alimentazione Supply voltage Tension d’alimentation
V/ph/HZ 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
Portata massima Max water flow Débit d’air maximum
l/h 14 14 14 14 295 295 295 295
Prevalenza massima
(verticale)
Max head pressure
(vertical)
Prevalence maximum
(verticale)
m 12 12 12 12 2 2 2 2
Serbatoio Tank capacity Vase tampon
l - - - - 4,3 4,3 4,3 4,3
POMPA SCARICO
CONDENSA
(versione D)
CONDENSATE
DRY PUMP
(C version)
POMPE DE DESCHARGE
DE LA CONDENSAZATION
(version D)
Alimentazione Supply voltage Tension d’alimentation
V/ph/HZ
230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
Portata massima Max water flow Débit d’air maximum
l/h 900 900 900 900 900 900 900 900
Prevalenza massima
(verticale)
Max head pressure
(vertical)
Prevalence maximum
(verticale)
m 6 6 6 6 6 6 6 6
Serbatoio Tank capacity Vase tampon
l 4,0 4,0 4,0 4,0 4,0 4,0 4,0 4,0
(1) Versione D + Resistenze elettriche
(2) Alla portata minima e massima percentuale
di regolazione
฀฀฀฀฀฀
฀฀฀฀฀฀฀฀฀
฀฀฀฀฀฀฀
meccanica
(1) D Version + Electrical Heaters
(2) At minimum airflow and maximum fan speed
฀฀฀฀฀฀฀฀
฀฀฀฀฀฀฀฀฀
- operation in dehumidification mode with mechanical
thermostat
(1) D Version + résistance électriques
(2) A la vitesse minimal
฀฀฀฀฀฀฀฀฀
฀฀฀฀฀฀฀฀฀
฀฀฀฀฀฀฀
mécanique
