Trane Odyssey TWA0724 A Series User Manual

10
SSP-SVX001B-EN
Heat Pump
Figure 2. Height, width and depth measurements
H
W
D
H
W
D
H - in. (mm) W - in. (mm) D - in. (mm)
TWA0604DA, 0724*A, 0764DA, 0904*A (R-410A) and
TWA0902*A (R-22)
39.125 (993.8) 42.125 (1070) 36 (914.4)
TWA0604DD, 0724*D, 0764DD, 0904*D (R-410A) 39.125 (993.8) 52.125 (1324) 40 (1016)
TWA1014DA/D, 1204*A/D (R-410A) and TWA1202*A (R-22) 45.125 (1146.1) 52.125 (1324) 40 (1016)
TWA1564DD, 1804*D, 2014DD, 2404*D (R-410A) and
TWA1802*D, TWA2402*D (R-22)
45.125 (1146.1) 95.5 (2425.7) 45.875 (1165.2)
