Trane Odyssey TWA0724 A Series User Manual

SSP-SVX001B-EN
23
Charging Levels
IImmppoorrttaanntt:: For the correct line diameter, for line
lengths greater than 25 feet, see the
Odyssey Application Guide (SS-APG008*-
EN) available through e-Library or your
local sales office.
Table 6. Estimated charge levels at ARI rated line lengths (25 feet)
Matched Set
Refrigerant Charge
Per Circuit
Circuit 1 Circuit 2
Liquid Line Diameter Vapor Line Diameter
TWA0604DA w/ TWE0764DA
16.6
N/A
0.5 (1/2”) 1.375 (1 3/8”)
TWA0604DD w/ TWE0724DB
11.1 12.4
0.5 (1/2”) 0.875 (7/8")
TWA0724*A w/ TWE0904*A
20.4
N/A
0.5 (1/2”) 1.375 (1 3/8”)
TWA0724*D w/ TWE0724*B
11.0 11.0
0.5 (1/2”) 0.875 (7/8")
TWA0764DA w/ TWE0764DA
19.0
N/A
0.625 (5/8”) 1.375 (1 3/8”)
TWA0764DD w/ TWE0764DB
11.7 11.7
0.5 (1/2”) 1.125 (1 1/8”)
TWA0904*A w/ TWE0904*A
19.0
N/A
0.625 (5/8”) 1.375 (1 3/8”)
TWA0904*D w/ TWE0904*B
11.8 11.8
0.5 (1/2”) 1.125 (1 1/8”)
TWA1014DA w/ TWE1014DA
34.7
N/A
0.5 (1/2”) 1.375 (1 3/8”)
TWA1014DD w/ TWE1014DB
14.0 14.0
0.5 (1/2”) 1.125 (1 1/8”)
TWA1204*A w/ TWE1204*A
34.7
N/A
0.5 (1/2”) 1.375 (1 3/8”)
TWA1204*D w/ TWE1204*B
14.0 14.0
0.5 (1/2”) 1.125 (1 1/8”)
TWA1564DD w/ TWE1564DB
19.2 19.9
0.5 (1/2”) 1.125 (1 1/8”)
TWA1804*D w/ TWE1804*B
27.2 24.5
0.5 (1/2”) 1.125 (1 1/8”)
TWA2014DD w/ TWE2014DB
18.6 18.4
0.625 (5/8”) 1.375 (1 3/8”)
TWA2404*D w/ TWE2404*B
23.5 23.5
0.625 (5/8”) 1.375 (1 3/8”)
Notes:
1. For line lengths other than 25', please refer to the Application Guide (SS-APG008*-EN) for charge levels, oil addition and line sizes.
2. For additional support with line lengths or refrigerant charge, refer to the Application Guide or contact Product Support.
3. TWA0604DA and TWA0724*A need a reducer for vapor line. (1.375 to 1.125) (1 3/8” to 1 1/8”).
4. TWA0604DD and TWA0724*D need a reducer for vapor line (1.125 to 0.875) (1 1/8" to 7/8").
IInnssttaallllaattiioonn
