Weights
Heat Pump Condenser
Table 1. TWA R-410A unit and corner weights — lbs (60 Hz)
Tons Model No.
Shipping
Max (lbs)
Net Max
(lbs)
Corner Weights
1 2 3 4
6
TWA0724*A 360 327 112 83 56 76
TWA0724*D 413 356 124 84 90 58
7.5
TWA0904*A 382 332 82 117 60 73
TWA0904*D 466 409 143 96 103 67
10
TWA1204*A 495 466 165 109 116 76
TWA1204*D 478 435 152 102 109 71
15 TWA1804*D 874 762 235 167 196 164
20 TWA2404*D 1003 845 253 265 147 181
Table 2. TWA R-22 unit and corner weights — lbs (60 Hz)
Tons Model No.
Shipping
Max (lbs)
Net Max
(lbs)
Corner Weights
1 2 3 4
7.5 TWA0902*A 397 339 116 86 58 79
10 TWA1202*A 482 437 126 121 72 118
15 TWA1802*D 920 762 201 191 181 190
20 TWA2402*D 1003 845 253 265 147 181
Table 3. TWA R-410A unit and corner weights — kg (50 Hz)
Tons Model No.
Shipping
Max (kg)
Net Max
(kg)
Corner Weights
1 2 3 4
5
TWA0604DA 163 148 50 38 25 34
TWA0604DD 185 159 54 38 41 26
6.25
TWA0764DA 173 150 37 53 27 33
TWA0764DD 209 183 63 44 47 30
8.33
TWA1014DA 224 211 74 49 53 34
TWA1014DD 215 195 67 46 50 32
13 TWA1564DD 395 344 106 75 89 74
16.7 TWA2014DD 453 382 114 120 67 82
