Panel Component Removal
Wye-Delta Panel
Note: For solid state starter panels, see “Solid State Starter
Panel,” p. 35.
WARNING
Hazardous Voltage w/Capacitors!
Failure to disconnect power and discharge capacitors
before servicing could result in death or serious injury.
Disconnect all electric power, including remote
disconnects and discharge all motor start/run
capacitors before servicing. Follow proper lockout/
tagout procedures to ensure the power cannot be
inadvertently energized. For variable frequency drives
or other energy storing components provided by Trane
or others, refer to the appropriate manufacturer’s
literature for allowable waiting periods for discharge of
capacitors. Verify with a CAT III or IV voltmeter rated per
NFPA 70E that all capacitors have discharged.
Figure 32. Wye-delta component locations
1K4
1K1
1K3
1K2
1R1 1R2 1R3
1A3
1T3-1
1T3-2
1T3-3
1F1/2/3 Fuse
Line-Side
Harness 1F1/2/3
High-Fault
Bracing
1T2-1
1T2-2
1T2-3
To Next Page
