Trane RTHD

Wiring Information
SO-SVN048A-EN 65
Wire Harness Details
Figure 104. Wire harness details
14/O
2 GND 1 AWG
3 FLEXIBLE CONDUIT 2.5 INCH
14/O
2 GND 1 AWG
3 FLEXIBLE CONDUIT 2.5 INCH
14/O
2 GND 1 AWG
3 FLEXIBLE CONDUIT 2.5 INCH
14/O
2 GND 1 AWG
3 FLEXIBLE CONDUIT 2.5 INCH
14/O
2 GND 1 AWG
3 FLEXIBLE CONDUIT 2.5 INCH
14/O
2 GND 1 AWG
3 FLEXIBLE CONDUIT 2.5 INCH
14/O
2 GND 1 AWG
3 FLEXIBLE CONDUIT 2.5 INCH
HARNESS P/N INDEX WIRE NO. / DESCRIPTION GAUGE / SIZE LENGTH (IN)
50711800
1 PWR - 1-L1, 1-L2, 1-L3 4/O 100
2 GND 1 AWG 94
3 FLEXIBLE CONDUIT 2.5 INCH 54.75
50711801
PWR - 2L-1, 2L2, 2L3 108
103
59.25
50711802
PWR - 1T-1, 1T-2, 1T-3 124
117
69.25
50711803
PWR - 2T-1, 2T-2, 2T-3 130
124
74.5
50711804
PWR - 1L-1, 1L-2, 1L-3 105
99
54.75
50711805
PWR - 2L-1, 2L-2, 2L3 113
108
59.25
50711806
PWR - 1T-1, 1T-2, 1T-3 129
122
69.25
50711807
PWR - 2T-1, 2T-2, 2T-3 135
129
74.5
3
2
1
