11
CGAF CGAF CGAF CGAF CGAF CGAF CGAF CGAF CGAF
90 100 110 130 140 150 165 180 190
SE SE SE SE SE SE SE SE SE
Single pump - High head pressure
option
Max available Head Pressure (kPa) 251 247 234 232 249 252 245 234 226
Motor Power (kW) 11 11 11 11 15 15 15 15 15
Rated Amps (A) 20.8 20.8 20.8 20.8 28 28 28 28 28
Twin pump - Standard head pressure
option
Max available Head Pressure (kPa) 123 115 98 92 142 137 124 164 155
Motor Power (kW) 5.5 5.5 7.5 7.5 7.5 7.5 11 11 11
Rated Amps (A) 11 11 14.4 14.4 14.4 14.4 20.8 20.8 20.8
Twin pump - High head pressure option
Max available Head Pressure (kPa) 251 247 234 232 249 252 245 234 226
Motor Power (kW) 11 11 11 11 15 15 15 15 15
Rated Amps (A) 20.8 20.8 20.8 20.8 28 28 28 28 28
Expansion Tank Volume (l) 50 50 50 50 50 50 50 50 50
Max User water loop Volume for
factory mounted expansion tank (1)
(l) 1750 1750 1750 1750 1750 1750 1750 1750 1750
Optional water Buffer tank volume (l) 607 607 607 607 777 777 777 777 777
Antifreeze Heater without pump
package and without buffer tank
(W) 360 420 420 420 540 640 640 640 640
Antifreeze Heater with pump
package and without buffer tank
(Single Water Pump digit 24=2 or 4
/ Dual Water Pump digit 24=1 or 3)
(W)
1000 /
1060
1060 /
1120
1060 /
1120
1060 /
1120
1240 /
1300
1340 /
1400
1340 /
1400
1340 / 1400 1340 / 1400
Antifreeze Heater with pump
package and with buffer tank
(Single Water Pump digit 24=2 or 4
/ Dual Water Pump digit 24=1 or 3)
(W)
1880 /
1940
1940 /
2000
1940 /
2000
1940 /
2000
2690 /
2750
2790 /
2850
2790 /
2850
2790 / 2850 2790 / 2850
Condenser
Type Full aluminium Micro channel heat exchanger
Quantity of coil # 6 6 6 6 8 8 8 10 10
Face area per circuit (m²) 8.88 8.88 8.88 8.88 11.84 11.84 11.84 14.8 14.8
Condenser Fan
Quantity # 6 6 6 6 8 8 8 10 10
Diameter (mm) 800
Fan / motor Type Propeller fan : Fixed speed AC motor / Variable speed EC motor
Digit 56=1
Fan / motor Type Fixed speed AC motor
Airow per fan m
3
/h 17118 17037 16935 16830 17005 16943 16865 16984 16921
Max Power Input per Motor Kw 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4
Max Amps per Motor A 2.8 2.8 2.8 2.8 2.8 2.8 2.8 2.8 2.8
Motor RPM (rpm) 900 900 900 900 900 900 900 900 900
Digit 56=2
Fan / motor Type Variable speed EC small motor
Airow per fan m3/h 17275 17197 17768 18558 17389 18221 19038 18038 18646
Max Power Input per Motor Kw 1.55 1.55 1.55 1.55 1.55 1.55 1.55 1.55 1.55
Max Amps per Motor A 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
Motor RPM (SN - LN) (rpm) 840 840 870 910 850 890 930 880 910
Motor RPM (XLN) (rpm) 830 830 830 830 830 830 830 830 830
Digit 56 =3 Variable speed EC strong motor
Fan / motor Type m3/h 18872 18792 19434 20814 19008 20431 21344 19976 20904
Airow per fan Kw 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82
Max Power Input per Motor A
2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9
Max Amps per Motor (rpm) 830 830 860 920 840 900 940 880 920
Motor RPM (SN - LN) (rpm) 780 780 780 780 780 780 780 780 780
Motor RPM (XLN) 800 800 800 800 800 800 800 800 800
Dimensions
Unit Length (mm) 3395 3395 3395 3395 4520 4520 4520 5645 5645
Unit Width (mm) 2200 2200 2200 2200 2200 2200 2200 2200 2200
Std Unit Height (mm) 2526 2526 2526 2526 2526 2526 2526 2526 2526
Pump Package Option - (Additional
length conguration)
(mm) 562 562 562 562 562 562 562 562 562
General Data
Table 1 – General data CGAF 090-190 Standard Efficiency (continued)
