Trane SINTESIS ADVANTAGE CXAF Series User Manual

10
CG-SVX039C-GB
Table 1 – General data CGAF 090-190 Standard Efficiency
CGAF CGAF CGAF CGAF CGAF CGAF CGAF CGAF CGAF
90 100 110 130 140 150 165 180 190
SE SE SE SE SE SE SE SE SE
Net Cooling Capacity (1) (kW) 676.1 632.5 567.8 524.9 491.0 441.0 397.8 355.2 321.4
Net Total Power input (1) (kW) 225.0 207.1 198.1 179.5 164.2 153.8 135.1 117.3 103.0
Unit electrical data (2) (3) (4)
Short Circuit Unit Capacity (kA) 15 15 15 15 15 15 15 15 15
Power Cable Cross Section (max)
mm²
1*240 1*240 1*240 1*240 2*300 2*300 2*300 2*300 2*300
Disconnect switch size (A) 400 400 500 500 630 630 630 800 800
Digit 56=1
Maximum Power input (kW) 142.0 161.1 175.3 189.5 220.8 240.0 254.2 271.2 285.4
Max. amps (A) 233.4 261.9 289.7 317.5 360.6 389.1 416.9 450.3 478.0
Unit start up amps (w/o soft starter
- digit 54=A) (4)
(A) 466.6 495.1 628.0 655.8 593.8 622.3 755.2 788.6 816.4
Unit start up amps (with soft starter
- Digit 54=B) (4)
(A) 349.0 377.5 462.8 490.6 476.2 504.7 590.0 623.4 651.2
Displacement power factor (dpf) 0.88 0.89 0.87 0.86 0.88 0.89 0.88 0.87 0.86
Digit 56=2
Maximum Power input (kW) 142.9 162.0 176.2 190.4 222.0 241.2 255.4 272.7 286.9
Max. amps (A) 231.6 260.1 287.9 315.7 358.2 386.7 414.5 447.3 475.0
Unit start up amps (w/o soft starter
- Digit 54=A) (4)
(A) 464.8 493.3 626.2 654.0 591.4 619.9 752.8 785.6 813.4
Unit start up amps (with soft starter
- Digit 54=B) (4)
(A) 347.2 375.7 461.0 488.8 473.8 502.3 587.6 620.4 648.2
Displacement power factor (dpf) 0.89 0.90 0.88 0.87 0.89 0.90 0.89 0.88 0.87
Digit 56=3
Maximum Power input (kW) 144.5 163.6 177.9 192.1 224.2 243.3 257.6 275.4 289.6
Max. amps (A) 234.0 262.5 290.3 318.1 361.4 389.9 417.7 451.3 479.0
Unit start up amps (w/o soft starter
- Digit 54=A) (4)
(A) 467.2 495.7 628.6 656.4 594.6 623.1 756.0 789.6 817.4
Unit start up amps (with soft starter
- Digit 54=B) (4)
(A) 349.6 378.1 463.4 491.2 477.0 505.5 590.8 624.4 652.2
Displacement power factor (dpf) (dpf) 0.89 0.90 0.88 0.87 0.90 0.90 0.89 0.88 0.87
Compressor
Compressor Number per Circuit # 2 2 2 2 3 3 3 3 3
Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll
Model Circuit 1 / Circuit 2 kW
25+30/
25+30
30+30/
30+30
30+40/
30+40
40+40/
40+40
25+30+30/
25+30+30
30+30+30/
30+30+30
30+30+40/
30+30+40
30+40+40/
30+40+40
40+40+40/
40+40+40
Max Comp Power input Circuit 1 /
Circuit 2
kW
28.4+38.2/
28.4+38.2
38.2+38.2/
38.2+38.2
38.2+45.2/
38.2+45.2
45.2+45.2/
45.2+45.2
28.4+38.2
+38.2/28.4
+38.2+38.2
38.2+38.2
+38.2/38.2
+38.2+38.2
38.2+38.2
+45.2/38.2
+38.2+45.2
38.2+45.2
+45.2/38.2
+45.2+45.2
45.2+45.2
+45.2/45.2
+45.2+45.2
Rated Amps Circuit 1 / Circuit 2 (A)
47+61/
47+61
61+61/
61+61
61+75/
61+75
75+75/
75+75
47+61
+61/47
+61+61
61+61
+61/61
+61+61
61+61
+75/61
+61+75
61+75
+75/61
+75+75
75+75
+75/75
+75+75
Locked Rotor Amps Circuit 1 / Circuit
2 (direct start - Digit 54=A)
(A)
260+294/
260+294
294+294/
294+294
294+413/
294+413
413+413/
413+413
260+294
+294/260
+294+294
294+294
+294/294
+294+294
294+294
+413/294
+294+413
294+413
+413/294
+413+413
413+413
+413/413
+413+413
Locked Rotor Amps Circuit 1 / Circuit
2 (Soft starter - Digit 54=B)
(A)
156+176/
156+176
176+176/
176+176
176+248/
176+248
248+248/
248+248
156+176
+176/156
+176+176
176+176
+176/176
+176+176
176+176
+248/176
+176+248
176+248
+248/176
+248+248
248+248
+248/248
+248+248
Motor RPM (rpm) 2900 2900 2900 2900 2900 2900 2900 2900 2900
Oil sump heater Circuit 1 / Circuit 2 (W)
90+90/
90+90
90+90/
90+90
90+90/
90+90
90+90/
90+90
90+90+90/
90+90+90
90+90+90/
90+90+90
90+90+90/
90+90+90
90+90+90/
90+90+90
90+90+90/
90+90+90
Evaporator
Quantity # 1 1 1 1 1 1 1 1 1
Type Stainless steel Copper Brazed plate Heat exchanger
Evaporator model
DFX650x106 DFX650x122 DFX650x138 DFX650x166 DFX650x166 DFX650x194 DFX650x222 DFX650x250 DFX650x278
Evaporator Water Content volume (l) 31 35.7 40.4 48.6 48.6 56.7 64.9 73.1 81.3
Nominal water connection size
(Grooved coupling) - Without HYM
(in) -
(mm)
4" -114.3 4" -114.3 4" -114.3 4" -114.3 5" -139.7 5" -139.7 5" -139.7 5" -139.7 5" -139.7
Nominal water connection size
(Grooved coupling) - With HYM
(in) -
(mm)
4" -114.3 4" -114.3 4" -114.3 4" -114.3 5" -139.7 5" -139.7 5" -139.7 5" -139.7 5" -139.7
Hydraulic Module Components
Single pump - Standard head pressure
option
Max available Head Pressure (kPa) 123 115 98 92 142 137 124 164 155
Motor Power (kW) 5.5 5.5 7.5 7.5 7.5 7.5 11 11 11
Rated Amps (A) 11 11 14.4 14.4 14.4 14.4 20.8 20.8 20.8
