General Data
CGAF CGAF CGAF CGAF CGAF CGAF CGAF CGAF CGAF
90 100 110 130 140 150 165 180 190
SE SE SE SE SE SE SE SE SE
Weights (6)
Shipping Weight (6) (kg) 2085 2200 2260 2325 2825 3005 3070 3435 3505
Option Additional shipping
weight (6)
Single pump - Standard head
pressure
(kg) 215 220 225 225 230 230 295 310 305
Single pump - High head pressure (kg) 260 265 265 260 305 305 305 320 320
Twin pump - Standard head
pressure
(kg) 300 305 325 320 325 325 440 450 450
Twin pump - High head pressure (kg) 385 390 385 385 460 460 465 480 475
XLN option (kg) 115 115 115 115 150 150 150 150 150
Pump VFD option (kg) 70 70 70 70 70 70 70 70 70
Partial heat recovery option (Digit
19 = N)
(kg) 45 45 65 65 75 75 75 75 75
Partial heat recovery option (Digit
19 = P)
(kg) 45 45 45 45 75 75 75 75 75
Water Buffer tank option (kg) 250 250 250 250 330 330 330 330 330
System data
Nb of refrigerant circuit # 2 2 2 2 2 2 2 2 2
Minimum cooling load % (6) % 23 25 21 25 15 17 15 14 17
Total number of capacity steps # 8 4 8 4 14 6 14 14 6
Standard/Partial Heat Recovery Unit
R410A refrigerant charge
Circuit 1 / Circuit 2
(kg) 18 / 18 19 / 19 19.5 / 19.5 20.5 / 20.5 30 / 30 32 / 32 33 / 33 38 / 38 39 / 38
Oil charge Circuit 1 / Circuit 2 (l)
14.2 /
14.2
14.2 /
14.2
14.2 /
14.2
14.2 /
14.2
22.1 /
22.1
22.3 /
22.3
22.3 /
22.3
22.3 /
22.3
22.3 /
22.3
Oil charge Circuit 1 / Circuit 2 (l)
16.2 /
16.2
16.2 /
16.2
16.2 /
16.2
16.2 /
16.2
24.1 /
24.1
24.3 /
24.3
24.3 /
24.3
24.3 /
24.3
24.3 /
24.3
POE Oil type OIL058E / OIL057E
(1) Indicative performance at Evaporator water temperature : 12°C / 7°C - Condenser air temperature 35°C - for detailed performances, on a given unit,
consult Order Write Up.
(2) Under 400V/3/50Hz.
(3) Rated Condition without Pump Package.
(4) Electrical & system data are indicative and subject to change without notice. Please refer to unit nameplate data.
(5) If the power line of the unit is protected by fuses gG of the same size as the disconnect switch.
(6) For detail information refer submittal drawing which are available in the unit.
Table 1 – General data CGAF 090-190 Standard Efficiency (continued)
