RLC-SVX19J_SHORT-GB
4
Pre-Installation
Installation Requirements
A list of the contractor responsibilities typically associated with the unit installation process is provided in Table 1.
Table 1
–
Installation requirements
Type
Trane Supplied
Trane Installed
Trane Supplied
Field Installed
Field Supplied
Field Installed
Foundation • Meet foundation requirements
Rigging
• Safety chains
• Clevis connectors
• Lifting beam
• Spreader bar
Isolation
• Elastomeric
isolators
(optional)
• Elastomeric isolators (optional)
Electrical
• Circuit breakers
(optional)
• Unit mounted
starter
• Circuit breakers (optional)
• Electrical connections to unit mounted starter
• Wiring sizes per submittal and NEC
• Terminal lugs
• Ground connection(s)
• BAS wiring (optional)
• Control voltage wiring
• Chilled water pump contactor and wiring
• Option relays and wiring
Water piping • Flow switch
• Taps for thermometers and gauges
• Thermometers
• Water fl ow pressure gauges
• Isolation and balancing valves in water piping
• Vents and drain
• Waterside pressure relief valves
• Water strainer
Insulation • Insulation • Insulation
Water Piping Connection Components • Grooved pipe
Other Materials
• R-134a, R-513A
or R1234ze
refrigerant
• Full factory
charge or pre-
load charge
• Dry nitrogen
(optional)
• Glycol for Glycol free confi guration
“Sintesis Model RTAF Installation
Completion Check Sheet and Request
for Trane Service”
Chiller Start-up Commissioning
(a)
• Trane, or an
agent of Trane
specifi cally
authorized to
perform start-
up of Trane
®
products
(a)
Start-up must be performed by Trane or an agent of Trane specifi cally authorized to perform start-up and warranty of Trane® products. Contractor
shall provide Trane (or an agent of Trane specifi cally authorized to perform start-up) with notice of the scheduled start-up at least two weeks prior to the
scheduled start-up.
