18 CLCH-SVX07C-EN
Unit Dimensions and Weights
Unit size 3 4 6 8 10 12 14 17 21 25 30
Coil
-Small horizontal (with 4-row UW)
10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00
127.31 164.68 191.68 226.20 269.31 310.76 335.50 384.32 467.78 533.75 609.14
-Medium horizontal (with 8-row UW)
14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00
179.86 236.36 282.91 339.38 407.35 475.70 516.37 601.64 734.68 848.92 978.12
-Extended-medium horizontal
(with 8-row UW)
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
196.79 255.65 303.39 361.57 431.62 501.63 544.40 631.09 772.37 889.31 1021.94
-Medium-large horizontal
(with 10-row W)
24.50 24.50 24.50 26.50 26.50 26.50 26.50 26.50 26.50 26.50 26.50
281.83 375.92 450.41 575.29 681.45 802.89 912.98 1045.42 1296.51 1509.94 1738.41
-Large horizontal or vertical
(with 10-row W)
34.00 34.00 34.00 36.00 36.00 36.00 36.00 36.00 34.00 46.00 46.00
313.98 412.58 489.32 617.44 727.56 852.16 966.23 1113.15 1368.11 1683.65 1926.83
Fan
6
-Belt-drive plenum fan with motor
36.00 41.00 41.00 44.00 42.50 42.50 42.50 44.00 50.25 56.50 56.50
406.54 537.13 625.09 674.57 864.70 936.46 1052.78 1214.74 1414.95 1495.75 1736.99
-Housed fan (FC/AF/BC) with motor
36.00 41.00 41.00 44.00 42.50 42.50 42.50 44.00 50.25 56.50 56.50
387.54 466.14 568.41 641.41 839.41 904.62 925.53 1073.07 1403.49 1535.79 1755.04
-Direct-drive plenum fan with motor
36.00 41.00 41.00 44.00 46.75 48.50 48.50 50.00 50.25 50.25 52.50
335.20 450.11 446.52 576.33 663.63 746.10 767.31 799.69 1095.84 1182.66 1263.84
Controls section (includes largest
available VFD)
24.50 24.50 24.50 24.50 24.50 24.50 24.50 24.50 24.50 24.50 24.50
234.30 247.41 276.71 299.47 318.94 332.69 414.48 423.00 442.03 463.11 486.63
Diffuser
10.00 10.00 10.00 14.00 14.00 14.00 14.00 14.00 14.00 19.00 19.00
53.76 63.14 68.53 90.94 100.86 116.94 121.90 129.34 143.02 185.04 199.78
Discharge plenum
7
-Horizontal
34.00 34.00 34.00 36.00 36.00 36.00 36.00 36.00 34.00 46.00 46.00
150.01 185.36 196.57 230.30 251.17 270.87 284.72 307.99 376.33 367.37 404.25
-Vertical
36.00 41.00 41.00 44.00 42.50 42.50 42.50 44.00 50.25 56.50 56.50
177.24 209.05 221.00 259.71 285.68 308.68 325.46 351.14 429.14 497.02 549.91
Blender
19.00 24.50 24.50 26.50 36.00 36.00 36.00 36.00 34.00 46.00 46.00
94.86 132.71 146.30 173.34 238.64 264.12 276.73 303.71 323.59 427.13 470.25
Electric Heat
36.00 41.00 41.00 44.00 42.50 42.50 42.50 44.00 50.25 56.50 56.50
261.39 309.88 335.38 449.00 471.92 500.13 513.26 627.76 705.10 857.44 898.23
Face-and-Bypass Dampers
-Internal face-and-bypass or
face damper only
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
122.68 155.15 167.79 190.70 219.68 241.45 255.80 270.77 300.08 317.53 353.22
-External face-and-bypass
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
105.60 129.06 141.70 157.63 178.68 199.15 209.53 224.50 248.05 265.62 291.36
Energy Wheel
n/a 52.25 52.25 52.25 54.50 57.50 57.50 57.50 55.50 55.50 57.50
n/a 364.17 378.70 457.21 561.31 676.15 766.30 786.59 879.93 917.84 1135.01
CDQ Wheel
52.25 52.25 52.25 52.25 54.50 57.50 57.50 57.50 55.50 55.50 57.50
284.39 406.17 420.70 484.21 661.31 756.15 884.30 905.99 1189.41 1213.44 1310.61
Integral-face-and-bypass coil
-Less than 4 rows
n/a 26.50 26.50 26.50 26.50 26.50 26.50 26.50 26.50 26.50 26.50
n/a 355.20 367.21 470.21 541.93 585.86 619.66 733.14 792.88 805.52 940.46
-4 rows
n/a 43.00 43.00 43.00 43.00 43.00 43.00 43.00 43.00 43.00 43.00
n/a 543.54 559.47 723.32 834.36 900.62 950.23 1130.33 1220.11 1403.29 1443.62
Table 4. Section dimensions (inches) and weights (pounds) - unit sizes 3-30
